Key advantages

Low power/long battery life
Very high contrast
Vivid color
Small form factor
Wide temperature range

Many on-chip functionalities
Highest brightness color display demo’d
Fine pitch OLED process demo’d
Color 9.6 µm pitch in production
Refresh rate 30Hz to 240Hz

No smear
No illuminator, heater or drive chip
9.3 µm to 15 µm pixel pitch
0.47” to 1.06” display diagonal
Field tested for reliability and performance > 20 years

Technology Timeline

(Images are not true to size)

2000

eMagin Microdisplay and Headset Firsts

2001Commercial full color SVGA+ Active Matrix OLED microdisplay
2006Headset (Z-800); Best of Innovations Award at CES
2009Full color SXGA OLED microdisplay
2011 Full Color WUXGA OLED Microdisplay &
High-brightness Monochrome SXGA120 Microdisplay (20K+ cd/m2)
2012 Full HD+ 3D stereoscopic headset
2013High-brightness Color SXGA096 OLED Microdisplay (700+ cd/m2)
2014 Increased product portfolio
20154 Megapixel Immersive Headset
2016 eMagin New Direct Patterning Technology (Ultra high-brightness 5,000+ cd/m2 on WUXGA)
2017Direct Patterning Technology demonstrated on 2Kx2K OLED Microdisplay
2018 Direct Patterning Technology Enhancements (>7,500 cd/m2 brightness full color WUXGA)
2019 4Kx4K Microdisplay
Demonstrated at SID Conference
2021 Full color directly patterned 4Kx4K demo
Demonstrated at SID Conference
2022 Won People’s Choice Award at SID Display Week for Best New Technology
10,000 cd/m2 dPD OLED display
2023 eMagin Demonstrates 15,000 cd/m2 maximum brightness with Single-stack Full-color dPd™ technology
2024 Recent demonstration of 3,500 PPI with D65 white directly patterned (dPd™) microdisplay jointly with SDC

ULT Direct Patterning

Additional Microdisplay Life Tests NVESD

2K ULT Direct Patterning

WUXGA HMD

Ultra-High Resolution AMOLED

Microdisplay Life Tests NVESD

Worldwide Patents: 83 Total/44 Issued & 39 Pending

Our displays use a number of the following issued US patents:

6,608,283	8,649,098	9,385,323	10,297,645
6,657,224	8,749,456	9,443,913	10,345,602
6,853,491	8,766,883	9,489,887	10,386,731
7,233,026	8,883,553	9,733,481	10,483,478
7,745,340	8,944,873	9,793,252	10,522,794
8,232,931	8,961,254	9,899,456	10,578,879
8,305,690	8,974,263	9,984,616	10,636,969
8,423,309	8,975,832	10,072,328	10,644,239
8,456,745	9,142,779	10,128,317	10,741,129
8,564,187	9,366,871	10,147,906

Our digital displays VGA, DSVGA, SXGA096, SXGA120, WUXGA and 2k x 2k, may use the following U.S. Patents numbered:

7,573,068

7,868,880

8,139,007

(Available – Q1 2021)

White OLED with RGB Color Filter Single Unit Device (Non-Tandem) Luminance Nominal: ~1,500 cd/m² Maximum ~3,000 cd/m² Applicable to all resolutions

eMagin’s Revolutionary New Direct Patterning (dPd^TM) Technology

eMagin’s dPd technology uses Red, Green and Blue emitters that are super bright vs traditional displays that use a white OLED with a RGB color filter that robs 80% of the light
OLEDs made with dPd technology have potential to produce full color microdisplays with brightness of over 28,000 cd/m²^, a level the competition can only reach with monochrome displays
Ongoing improvements in optics, lens and device architectures will put eMagin’s dPd technology further ahead of the field
Display made using dPd technology consumes less power and the color gamut is among the best in the industry

graf

eMagin’s dPd technology renders colors true to the demanding color gamut required by the new Digital Cinema Initiatives DCI-P3 standards
